PR RACING introduces the latest version of the popular PRSB401 for 2018 in the form of a light weight Type-R version named the SB401-R Type-R.
PR racing have been hard at work developing the next generation of the successful SB401 platform and have made the SB401-R faster, quieter and easier to maintain and tune.
A number of key components have been totally redesigned to produce a better handling and more forgiving car to drive. The main focus has been on the all new narrow 2mm 7075-T6 chassis and plastic side-pods, which utilizes a carbon fibre re-enforced spine to control torsional and longitudinal flex. The additional flex has proved to increase grip, and make the car feel more balanced and easier to drive leading to faster, more consistent laps.
Chassis
• Hard anodized 2mm 7075-T6 Narrow chassis with side-pods
• Plastic/carbon chassis spine with CNC alloy bulkheads
• Alloy/Carbon floating servo mount
• Improved weight distribution with motor and slipper 10mm forward
• Type R ultra-low CG Body
Transmission
• New stronger/quieter pinions and ring gears
• New vented slipper assembly with ultra-hard shafts and cups for long life
• Top loading slipper/center diff mount for easy access
• Longer diff cups to allow for more droop
Suspension and Steering
• 12.75mm Type R shocks
• Lower towers for ultra-low CofG
• Suspension hangers with inserts for toe and anti-squat adjustment
• Revised Ackerman geometry for improved steering feel
• New shock seal caps and seals for ultra-smooth operation
• 11 Degree CNC caster blocks
• CNC alloy rear hubs
• Gullwing rear wishbones
• Hard front wishbones
• New shorter grey ball-cups
• New high tensile steel turnbuckles
Specifications
Type: 1/10th 4wd Off-Road
Power Source: Electric
Wheelbase:287(variable)
Width:245mm-248mm
Gear Ratio: 2.6:1
Weight 1705g-1720g race ready (varies)
Hardware: Full metric
Bearings: Sealed Metal Ball Bearings
Wheels: 12mm hex
Kit: Assembly required
Minimum Age Recommendation: 14 years old.
Items Required to Complete
2 Channel surface frequency radio system
2S LiPo battery & compatible lipo charger
1/10 ESC, motor & pinion gear
High-Speed Servo
1/10 tires and inserts
Tools, paint for polycarbonate body, tire glue, threadlock
Silicon diff and shock oil
